Specificatii tehnice


Dual mono construction valve pre-amplifier equipped with two ECC82 double triodes
Carefully selected and ´burnt-in` (60 hours) valves from Russia
MM/MC phono pre-amplifier with low-noise operational amplifiers
Two record players / pick-ups may be connected simultaneously to separate input sockets for MM and MC
Four high-level inputs
Additional front panel mounted 3.5 mm audio input for portable devices
Input selection by precision relay
Volume and balance controlled by high precision ALPS potentiometers
Power amplifier with high-quality power transistors by Sanken and fully discrete circuitry
Sophisticated Dual Mono power supplies and generously dimensioned toroidal transformer
Separate standby mode for minimal energy consumption when not in use
Dot matrix display that can be switched off
Generously dimensioned and insulated loudspeaker connector terminals
Output terminals provide for bi-wired operation
Headphone output
Substantial chassis with machined eight millimetre thick aluminium front panel
Elegant full-metal system remote for controlling

Dimensiuni: 430mm x 125mm x 330mm
Greutate: 11,0 kg
Putere RMS: Nominal: 20 Hz - 20 kHz, THD < 1.0%, 4 Ohm 2 x 110 W 20 Hz - 20 kHz, THD < 1.0%, 8 Ohm 2 x 75 W
Raport Semnal/zgomot: CD/Tuner/Aux/Line/Tape 110dB
Phono MM 88dB
Phono MC 75dB
Raspuns in frecventa: CD/Tuner/Aux/Line/Tape 5 Hz - 100 kHz (-3,0 dB) 20 Hz - 20 kHz (+/-0,1 dB)
Phono 20 Hz - 20 kHz (+/-0,3 dB)
Subsonic Filter: 16Hz, 18dB/Oct.
Sensibilitatea de intrare: CD/Tuner/Aux/Line/Tape 400mV/100 kOhm
Phono MM 2mV/47 kOhm
Phono MC 0,3mV/470 Ohm
