Specificatii Tehnice


Amplificator 1 canal, clasa D
Putere Nominala (RMS)
1 x 600 W ( 4 ohmi )
1 x 600 W ( 2 ohmi )
Putere Maxima
1 x 1200 W ( 4 ohmi )
Raport semnal/zgomot >88dB
Raspuns in frecventa 20Hz-200Hz
Distorsiuni THD <1% (la puterea maxima)
Filtru Low Pass 50-200 Hz, 24 dB/octave
Filtru Subsonic 15Hz/30Hz
Sensibilitate intrare:200mV - 2.5 Volts
PWM (Pulse Width Modulated) MOSFET power supply
Salt/fog resistant (ASTM B117)
UV weathering protection (ASTM G154/D4329)
LED power and protection indicators
STAR (Signal Transit for Accurate Response) Topology (minimizes internal noise and prevents ground interference)
Stackable operation: Alpine PDX amplifiers are all one size, allowing for space saving stacked configuration
Hidden control panels behind removable metal plating
Adjustable gain control and gain range
Preamp RCA outputs (non-fading)
Constructed from UV resistant materials and finish, and corrosion resistant hardware
4-Layer glass epoxy PC board
Low resistance, high current speaker terminals
Over-current, thermal, and DC protection circuitry
Compact heavy duty aluminum alloy heatsink
Gold-plated RCA level inputs
Gold-plated screw terminals
Sigurante 4 x 20A
Telecomanda cu fir pentru Bass boost si Gain
Dimensiuni 2257 x 192 x 62mm
